New product Monel 400 wire mesh

Huaxi WIre Mesh offer you new product Monel 400 wire mesh

Monel 400 Wire Mesh is a superior resistant to corrosion that is caused by the sea water, stress corrosion cracking in the freshwater, dry hydrochloric and hydrofluoric acids. It can be easily used in the non-oxidizing chloride solutions. It attains large strength and causes resistance to the salt and caustic solutions.

Monel 400 Wire Mesh offers tremendous resistance to chloride stress corrosion cracking in the variety of environments. It is an excellent resistant to reducing agents.

Monel 400 Wire Mesh offers great mechanical properties at the subzero temperatures. The strength and toughness are enhanced by nominal alteration in ductility. It doesn't introduce ductile to brittle transition even at freezing point of hydrogen.

Characteristics of Monel 400 wire mesh:

  1. Hefty resistant to seawater and steam at high temperatures.
  2. Superior resistance to rapidly flowing brackish water or seawater, stress corrosion cracking in most freshwaters.
  3. Especially resistant to dry hydrochloric and hydrofluoric acids and sulfuric acids.
  4. High Resistance to neutral and alkaline salt and alkalies.

Applications of Monel 400 wire mesh;

  1. Seawater Operations.
  2. Gasoline and freshwater tanks and crude petroleum.
  3. Boiler feed water heaters and heat exchange equipments.
  4. Valves, pumps, fasteners and chloride solvents.





Chemical composition ofMonel 400 wire mesh

C
Mn
S
Si
Ni
Cu
Fe
.30 max
2.00 max
.024 max
.50 max
63.0 min
28.0-34.0
2.50 max



Applications of Monel 400 wire mesh;

  1. Seawater Operations.
  2. Gasoline and freshwater tanks and crude petroleum.
  3. Boiler feed water heaters and heat exchange equipments.
  4. Valves, pumps, fasteners and chloride solvents.

Specifications of Monel 400 wire mesh screen

Mesh Size 0.2 Mesh/Inch to 250 Mesh/Inch
Thickness 0.1mm-5.0mm
Aperture Rate 10%-90%

We provide our customers with excellent services. If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
